Round led stadium light 600w

100

Description

The most powerful LED light ,replacing more than 2000W MH/HPS lamps.Meanwell driver provide superior performance,separate driver box design,better for heat dissipation and maintenance.Various beam angle 10°/25°/45°/60° are available for optiomal,more uniform light distribution.Lamp cap available,avoid the light glare.

Highlights

  • Using LUMILEDS 5050,high lumen efficient reach to 150lm/w.
  • Three mounting type for your option
  • IP67 rating is applicable to outdoor environment.
  • More than 50,000 hours lifespan with 5 years warranty.
icon01
icon03
Specification
Product Dimension
User Manual
Application Cases
Product specification
Model No. SW-TS06-W600
Rated Power 600W
Input Voltage AC100-277V, 50/60Hz, 2.28A(at 230v);347V/480V AC for option
PF: >0.97
IP Grade: IP66
THD: 10%(at 230v, 50Hz)
Surge protection: L/N-PE: 10KV, L-N: 6KV; 20KV version is for option.
LED Parameters
LED chip SMD5050 LED
Light Efficiency 150-160LM/W
Color Temperature 2700-7000k
CRI >70Ra or 80Ra
Beam Angle 10°, 25°, 60°
Mechanical Specification
Body Material Die-casting aluminum
Lens Material PC lens
Body color Black
Operating Temperature -35℃ – 50℃
Net W./Gross W 19.0KGS / 23.0KGS(one piece)
Packing size 80x57x27CM, One piece in one carton
Warranty 5 years warranty
Certificates CE, RoHS

stadium light

500W SIZE

Warning:

  1. Before installation or wiring the lamps, please make sure the power is switched off;
  2. Before cleaning or repairing the lamp, please make sure the power is switched off;
  3. The lamp body will be very hot while working, do not touch it with your hand.

Led stadium light widely use in airport, seaport, sports lighting and other high mast lighting. It have professional lighting distribution, easy to install, more energy saving.
