New Led Linear High Bay L400B-W100 V2



Patent housing design with perfect heat dissipation.Different beam angle 120°x120°; 60°x100°;30°x100°.Two mounting type:Chain hanging mount and ceiling/wall mount for option.Simple and pretty appearance, exclusive high-end products. Surely will bring you incomparable refreshing experience.


  • High light efficiency 150-160lm/w
  • Long lifespan, 5 years warranty with Sosen & Mean Well driver
  • CE, RoHS, SAA,DLC, ETL certificates approved.
  • DALI, ZigBee, motion sensor, and 1-10V dimmable are available
Product Dimension
User Manual
Application Cases
Product specification
Model No. SW-L400B-W100 V2
Rated Power 100W
Input Voltage AC100-277V, 50/60Hz;0.48A(at 220v)
PF: >0.95
IP Grade: IP65
THD: 8%(at 230v, 50Hz)
Surge protection: L/N-PE: 6KV, L-N: 4KV; 10/20KV version is for option.
LED Parameters
LED chip SMD3030 LED
Light Efficiency 150-160lm/w
Color Temperature 2700-7000k
CRI >70Ra or 80Ra
Beam Angle 120°x120°; 60°x100°;30°x100°
Mechanical Specification
Body Material Aluminum
Lens Material Chain hanging type, or ceiling/wall mounted
Mounting type: grey
Operating Temperature -35℃ – 50℃
Net W./Gross W 2.6KGS(1PCS)/ 6.0KGS(2PCS)
Packing size 63*30*16cm(2PCS)
Warranty 5 years warranty
Certificates CE, RoHS, SAA, ETL


4 拷贝



  1. Before installation or wiring the lamps, please make sure the power is switched off;
  2. Before cleaning or repairing the lamp, please make sure the power is switched off;
  3. The lamp body will be very hot while working, do not touch it with your hand.


Linear led high bay light widely used inwarehouse, workshop, supermarkets, exhibition room, hall, toll station, gas station, residential areas, industrial areas, etc.


In Addition To Quality Lights, We Provide...

Effective Solution

Tell us your needs and our professional in-house engineers will give you professional lighting solutions including specific parameters which is more than satisfaction.


One-stop shop for your lighting projects; Lamp body, lighting performance, material of lights,etc. all can be tailored to your specific requirements. Tell us your ideas, we make it real.

Fast Delivery

Time is money. We are deeply aware of what time means to your business. Standard orders are shipped within 1 week from getting your orders. Cooperate with SNOOWEL, coordinate with your schedule.


Each and every light is backed up with long warranty period of 5-7 years. Any concern including LED lights and components are covered in it. Our after-sales support team is always ready to help you.
