Led sport light 1000w

100

Description

The most powerful LED light ,replacing more than 2000W MH/HPS lamps. Heat pipe reveted fin heat dissipation technology is adopted solve the problem of high-power heat dissipation to ensure longer chip drive life. External power supply equipped with anti-surge configuration

Highlights

  • Using SMD3030 led chip as light source,lumen efficency can reach 150-160lm/w.
  • IP65 design,can be used outdoor directly
  • 216° adjustable angle
  • High performance Sosen/Mean well driver,5 years warranty
icon01
icon03
Specification
Product Dimension
User Manual
Application Cases
Product specification
Model No. SW-H001B-W1000
Rated Power 1000W
Input Voltage AC100-277V, 50/60Hz, 3.6A(at 230v); 347V/480V for option
PF: >0.97
IP Grade: IP65
THD: 10%(at 230v, 50Hz)
Surge protection: L/N-PE: 10KV, L-N: 6KV; 20KV version is for option.
LED Parameters
LED chip CREE XTE
Light Efficiency 140-150LM/W
Color Temperature 2700-7000k
CRI >70Ra or 80Ra
Beam Angle 45°, 60°
Mechanical Specification
Body Material Aluminum
Lens Material PC lens
Body color Black
Operating Temperature -35℃ – 50℃
Net W./Gross W 26.5KGS / 29.0KGS(one piece)
Packing size 64x56x59CM, One piece in one carton
Warranty 5 years warranty
Certificates CE, RoHS

2HCZPF37WR59GV8XEJD

1000W SIZE

Warning:

  1. Before installation or wiring the lamps, please make sure the power is switched off;
  2. Before cleaning or repairing the lamp, please make sure the power is switched off;
  3. The lamp body will be very hot while working, do not touch it with your hand.

1ad838f602

Widely used in yard, sports field, square, construction site, etc.
