New Led Linear High Bay L400B-W400/W500 V2

100

Description

Patent housing design with perfect heat dissipation.Different beam angle 120°x120°; 60°x100°;30°x100°.Two mounting type:Chain hanging mount and ceiling/wall mount for option.Simple and pretty appearance, exclusive high-end products. Surely will bring you incomparable refreshing experience.

Highlights

  • High light efficiency 150-160lm/w
  • Long lifespan, 5 years warranty with Sosen & Mean Well driver
  • CE, RoHS, SAA,DLC, ETL certificates approved.
  • DALI, ZigBee, motion sensor, and 1-10V dimmable are available
icon06
icon02
icon05
icon01
icon03
Specification
Product Dimension
User Manual
Application Cases
Product specification
Model No. SW-L400B-W400 V2
Rated Power 400W/500W
Input Voltage AC100-277V, 50/60Hz;1.92A/2.39A(at 220v)
PF: >0.95
IP Grade: IP65
THD: 8%(at 230v, 50Hz)
Surge protection: L/N-PE: 6KV, L-N: 4KV; 10/20KV version is for option.
LED Parameters
LED chip SMD3030 LED
Light Efficiency 150-160lm/w
Color Temperature 2700-7000k
CRI >70Ra or 80Ra
Beam Angle 120°x120°; 60°x100°;30°x100°
Mechanical Specification
Body Material Aluminum
Lens Material Chain hanging type, or ceiling/wall mounted
Mounting type: grey
Operating Temperature -35℃ – 50℃
Net W./Gross W 9.6KGS/ 10.9KGS(1PCS)
Packing size 120*30*18cm(2PCS)
Warranty 5 years warranty
Certificates CE, RoHS, SAA, ETL



4 拷贝

500W SIZE 1

Warning:

  1. Before installation or wiring the lamps, please make sure the power is switched off;
  2. Before cleaning or repairing the lamp, please make sure the power is switched off;
  3. The lamp body will be very hot while working, do not touch it with your hand.

INSTALLATION

Linear led high bay light widely used inwarehouse, workshop, supermarkets, exhibition room, hall, toll station, gas station, residential areas, industrial areas, etc.

APPLICATION l400b
